Setting Up the Enterasys Matrix N7 Chassis
3-10 Enterasys Matrix N7 Chassis Setup
Figure 3-5 Rack Mounting the Enterasys Matrix N7 Chassis
1 Rack mounting screws (5 per side)
À À
1
45
6
7
23
50/60Hz
LINE 2:
100-125V~12A
200-240V~6A
50/60Hz
LINE 1:
100-125V~10A
200-240V~5A
POWER FAN
PS1
50/60Hz
LINE 2:
100-125V~12A
200-240V~6A
50/60Hz
LINE 1:
100-125V~10A
200-240V~5A
POWER FAN
PS2
