LANVIEW LEDs

2-4 Installation Requirements and Guidelines

2.3.2 Fan Tray LED

Refer to Figure 2-2 for the location of the fan tray LED. Table 2-2 describes the different states of

the fan tray LED.

Figure 2-2 Fan Tray LED

1 Fan tray LED

Table 2-2 Fan Tray LED States and Their Definitions

LED Color Status

Green All fans are operating normally.

Red One or more fan failures have occurred.

Note: When the N7 chassis is first powered up, the Fan Tray LED will display red

briefly, until the fans are operating at the proper speed.
