Installation Requirements and Guidelines 2-1
2
Installation Requirements and Guidelines
This chapter describes the following:
• Site guidelines that must be met before installing an Enterasys Matrix N7 chassis into a rack or
cabinet
• Enterasys Matrix N7 chassis configuration guidelines
• Operating specifications for the Enterasys Matrix N7 chassis enclosure and power supply
modules
2.1 SITE GUIDELINES
The following guidelines must be followed when a site is selected for the N7 chassis. If the
guidelines are not followed, unsatisfactory network performance may result.
• To allow proper cooling within the rack, there must be 7.62 centimeters (3 inches) of clearance
above the unit and 5.08 centimeters (2 inches) of clearance on either side of the unit.
• To install the N7 chassis as a freestanding unit on a shelving unit, the shelf must be able to
support 80 kilograms (176 pounds) of static weight.
• To install the N7 chassis as a rack mounted unit, care must be taken to ensure that the rack used
will support the unit and that the rack remains stable.
• The 6C207-3 ac power supplies for the N7 chassis require two three-pronged power receptacles
capable of delivering the current and voltage specified in Section A.2. Two ac outlets on
independently fused circuits are required for each 6C207-3, and must be located within
182 centimeters (6 feet) from the site. The power cord used and type of outlet is dependent on
the country. In the United States, two power cords with NEMA 5-15P plugs are provided with
each 6C207-3.
Electrical Hazard: Only qualified personnel should perform installation procedures.
Riesgo Electrico:
Solamente personal calificado debe realizar procedimientos de instalacion.
Elektrischer Gefahrenhinweis: Installationen sollten nur durch ausgebildetes und
qualifiziertes Personal vorgenommen werden.
