Network and Power Connections
2-10 Installation
• Power over Ethernet (PoE)
Power is provided through the RJ45 Ethernet port (LAN port) on the back of the WS-AP3705i.
This is the preferred method of powering the AP on ceiling and high wall installations.
• Power by external power supply
Where a PoE-capable Ethernet connection is unavailable or impractical, an external 48V DC
power supply may be ordered separately to power the WS-AP3705i from a standard AC wall
outlet. For more information on the installation process, see the section entitled “Connecting
the DC Power Supply to the WS-AP3705i” below.
Connecting the DC Power Supply to the WS-AP3705i
There is no wall mount for a DC power supply. To connect the power supply to the WS-AP3705i
for everyday operation, mount the AP and plug in the power supply as described in the section,
“Mounting the WS-AP3705i to a Wall,” on page 2-6. If you have taken the AP off its mount for
configuration and maintenance, plug the power cable from the DC power supply into the DC
connector on the back of the WS-AP3705i.
Note: Currently, the DC connector on the back of the WS-AP3705i is non-functional.
Draft
(Currently,Non-functional)
