MN-37072 • Rev 2 • 05/16 • Designer Series Blanket Warmer
Electrical Information
Locate Rating Tag
Verify power requirements. The power speci cation is located on the appliance identi cation
rating tag. This tag is permanently attached to the appliance.
Hazardous
Voltage Present
CAUTION
Power source must match voltage identified
on appliance rating tag. The rating tag
provides essential technical information
required for any appliance installation,
maintenance or repairs. Do not remove,
damage or modify the rating tag.
DANGER
To prevent serious injury, death, or
property damage:
Do not use this warming appliance in
the presence of flammable anesthetic
mixtures (with air or with oxygen or
nitrous oxide).
Not category AP or APG equipment
DC150 DC400
Power Requirements
For CE approved appliances: To prevent an
electrical shock hazard between the appliance and
other appliances or metal parts in close vicinity,
an equalization-bonding stud is provided. An
equalization bonding lead must be connected to
this stud and the other appliances/metal parts
to provide sufficient protection against potential
difference. The terminal is marked with the
following symbol.
Dimensions (H x W x D)
With feet (standard): 21.9" x 18.5" x 25.7" (557mm x 470mm x 653mm)
With plate and
casters
(optional):
26.3" x 18.5" x 25.7" (667mm x 470mm x 653mm)
With bumper and
casters (optional):
26.3" x 21.3" x 25.9" (667mm x 540mm x 657mm)
Capacity
2.5 
3
Weight** (est.)
Net: 67 lbs (30 kg) Ship: 118 lbs (54 kg)
Electrical
*Other international plugs are available, contact factory for more information.
**Domestic ground shipping information. Contact factory for export weight and dimensions.
120 V.A.C. — 60 Hz, 1 ph
0.6 kW, 5.0 Amps
Safety Class I Equipment
No Applied Parts
Mode of Operation: Continuous
NEMA 5-15P
15A - 125V Plug
Hospital Grade
IPX-0
E471516
220 V.A.C. — 50Hz, 1 ph
0.6 kW, 2.7 Amps
Type B Equipment
CEE 7/7*
220-230V Plug
IPX-0
230 V.A.C. — 50 Hz, 1 ph
0.6 kW, 2.6 Amps
Type B Equipment
BS 1363 Plug*
(UK only)
CEE 7/7*
220-230V Plug
IPX-0
Dimensions (H x W x D)
With feet (standard): 35.4" x 24.0" x 28.0" (900mm x 610mm x 712mm)
With bumper and
casters
(optional):
39.3" x 26.8" x 28.0" (997mm x 679mm x 712mm)
With casters
(optional): 40.7" x 24.0" x 28.0" (1033mm x 610mm x 712mm)
Capacity
7.5 
3
Weight** (est.)
Net: 134 lbs (61 kg) Ship: 196 lbs (89 kg)
Electrical
*Other international plugs are available, contact factory for more information.
**Domestic ground shipping information. Contact factory for export weight and dimensions.
120 V.A.C. — 60 Hz, 1 ph
0.8 kW, 6.7 Amps
Safety Class I Equipment
No Applied Parts
Mode of Operation: Continuous
NEMA 5-15P
15A - 125V Plug
Hospital Grade
IPX-0
E471516
220 V.A.C. — 50Hz, 1 ph
0.8 kW, 3.6 Amps
Type B Equipment
CEE 7/7*
220-230V Plug
IPX-0
230 V.A.C. — 50 Hz, 1 ph
0.8 kW, 3.5 Amps
Type B Equipment
BS 1363 Plug*
(UK only)
CEE 7/7*
220-230V Plug
IPX-0
Dimensions (H x W x D)
With feet (standard): 17.0" x 18.5" x 22.7" (431mm x 470mm x 577mm)
With casters
(optional): 20.5" x 18.5" x 22.7" (520mm x 470mm x 577mm)
Capacity
1.5 
3
Weight** (est.)
Net: 56 lbs (25 kg) Ship: 98 lbs (44 kg)
Electrical
*Other international plugs are available, contact factory for more information.
**Domestic ground shipping information. Contact factory for export weight and dimensions.
120 V.A.C. — 60 Hz, 1 ph
0.6 kW, 5.0 Amps
Safety Class I Equipment
No Applied Parts
Mode of Operation: Continuous
NEMA 5-15P
15A - 125V Plug
Hospital Grade
IPX-0
E471516
220 V.A.C. — 50Hz, 1 ph
0.6 kW, 2.7 Amps
Type B Equipment
CEE 7/7*
220-230V Plug
IPX-0
230 V.A.C. — 50 Hz, 1 ph
0.6 kW, 2.6 Amps
Type B Equipment
BS 1363 Plug*
(UK only)
CEE 7/7*
220-230V Plug
IPX-0
Dimensions (H x W x D)
With feet (standard): 21.9" x 24.0" x 28.0" (557mm x 610mm x 712mm)
With plate and
casters
(optional):
26.1" x 24.0" x 28.0" (664mm x 610mm x 712mm)
With bumper and
casters (optional):
26.2" x 26.8" x 28.9" (665mm x 679mm x 734mm)
Capacity
4.0 
3
Weight** (est.)
Net: 85-1/2 lbs (439 kg) Ship: 160 lbs (73 kg)
Electrical
*Other international plugs are available, contact factory for more information.
**Domestic ground shipping information. Contact factory for export weight and dimensions.
120 V.A.C. — 60 Hz, 1 ph
0.8 kW, 6.7 Amps
Safety Class I Equipment
No Applied Parts
Mode of Operation: Continuous
NEMA 5-15P
15A - 125V Plug
Hospital Grade
IPX-0
E471516
220 V.A.C. — 50Hz, 1 ph
0.8 kW, 3.6 Amps
Type B Equipment
CEE 7/7*
220-230V Plug
IPX-0
230 V.A.C. — 50 Hz, 1 ph
0.8 kW, 3.5 Amps
Type B Equipment
BS 1363 Plug*
(UK only)
CEE 7/7*
220-230V Plug
IPX-0
DC250 DC750
Dimensions (H x W x D)
With feet (standard): 27.9" x 18.5" x 25.7" (709mm x 470mm x 653mm)
With plate and
casters
(optional):
32.2" x 18.5" x 25.7" (819mm x 470mm x 653mm)
With bumper and
casters (optional):
32.2" x 21.3" x 25.9" (819mm x 540mm x 657mm)
Capacity
3.5 
3
Weight** (est.)
Net: 91 lbs (41 kg) Ship: 146 lbs (66 kg)
Electrical
*Other international plugs are available, contact factory for more information.
**Domestic ground shipping information. Contact factory for export weight and dimensions.
120 V.A.C. — 60 Hz, 1 ph
0.8 kW, 6.7 Amps
Safety Class I Equipment
No Applied Parts
Mode of Operation: Continuous
NEMA 5-15P
15A - 125V Plug
Hospital Grade
IPX-0
E471516
220 V.A.C. — 50Hz, 1 ph
0.8 kW, 3.6 Amps
Type B Equipment
CEE 7/7*
220-230V Plug
IPX-0
230 V.A.C. — 50 Hz, 1 ph
0.8 kW, 3.5 Amps
Type B Equipment
BS 1363 Plug*
(UK only)
CEE 7/7*
220-230V Plug
IPX-0
DC350
Safety Class I
Equipment
Protective Earth
Ground Symbol
Medical Equipment classi ed by Underwriters
Laboratories with Respect to Electrical Shock,
Fire and Mechanical Hazards only, in Accordance
with UL 61010–1 and CAN/CSA C22.2 No. 61010–1.
E471516
Grounding reliability can only be achieved when appliance is
connected to an equivalent receptacle marked “Hospital Grade.”
Wire diagram is located under top lid of appliance.
*Other international plugs are available, contact factory for more information.
