5.3 DIN Rail Evaluation unit
Fig. 13: DIN Rail dimensions
5.4 C1-Box dimensions (optional)
Fig. 14: C1-Box dimensions
Cable gland
M 20 x 1,5
Sensor 1Transmitter
118
35
23
90
