Form 1
Model designation
CQD12R/RF
CQD12R/RF
Sidesway
Mast Type
2-stage
3-stage
2-stage
3-stage
Overall length （minimum）
l
1
89.96
90.94
91.34
92.32
Length to face of forks
l
2
47.83
48.82
49.21
50.2
Reach distance
l
4
21.06
19.69
Aisle width for pallets 1000
× 1200 crossways
Ast
104.53
105.12
105.51
106.1
Aisle width for pallets 800
× 1200 lengthways
Ast
106.5
107.28
107.87
108.66
Aisle width for pallets 1000
× 1200 lengthways
Ast
108.46
109.25
109.65
110.43
Aisle width for pallets 800
× 1200 crossways
Ast
100.2
100.98
101.38
102.17
Form 2
Mast Type
Lift height(in.)
Service weight
（
without battery
）
lb.
CQD12R/RF
2-stage
98.43
4345
106.3
4389
118.11
4433
129.92
4477
141.73
4521
157.48
4576
169.29
4620
3-stage
137.8
4642
157.48
4708
177.17
4774
188.98
4818
196.85
4840
216.54
4906
