ep CQD20 - Page 15

8
Form 3
Mast Type
Lift height(in.)
Height, mast
lowered(in.)
Free lift (in.)
Height, mast
extended(in.)
h3
h1
h2
h2(*)
h4
h4(*)
2-stage
98.43
71.46
--
--
137.8
121.06
106.3
75.39
--
--
145.67
128.94
118.11
81.3
--
--
157.48
140.75
129.92
87.2
--
--
169.29
152.56
141.73
93.11
--
--
181.1
164.37
157.48
100.98
--
--
196.85
180.12
169.29
106.89
--
--
208.66
191.93
2-stage
Side sway
98.43
71.46
--
--
138.78
121.06
106.3
75.39
--
--
146.65
128.94
118.11
81.3
--
--
158.46
140.75
129.92
87.2
--
--
170.28
152.56
141.73
93.11
--
--
182.09
164.37
157.48
100.98
--
--
197.83
180.12
169.29
106.89
--
--
209.65
191.93
3-stage
137.8
68.31
29.13
45.87
177.17
160.43
157.48
74.8
35.63
52.36
196.85
180.12
177.17
81.3
42.13
58.86
216.54
199.8
188.98
85.24
46.06
62.8
228.35
211.61
196.85
87.8
48.62
65.35
236.22
219.49
216.54
94.29
55.12
71.85
255.91
239.17
3-stage
Side sway
137.8
68.31
28.15
45.87
178.15
160.43
157.48
74.8
34.65
52.36
197.83
180.12
177.17
81.3
41.14
58.86
200.79
199.8
188.98
85.24
45.08
62.8
212.6
211.61
196.85
87.8
47.64
65.35
220.47
219.49
216.54
94.29
54.13
71.85
240.16
239.17
Note：with(*)for without backrest parameters
