REV. 09/2021
13
B
Steering
Move the control hand to the left or right.
Right
Left
3.Braking
Mechanical operating brake
The truck is braked when the operating
handle is released.
The mechanical brake engages when the
tiller is positioned in (B
）
area.
If the control handle moves slowly into
the brake position, identify the cause and
rectify the fault. If necessary, replace the
spring!
CAUTION
Regenerative braking
Release the drive switch. The drive
switch will automatically return to the
initial position and the vehicle will begin
to enter the regenerative braking state.
When it decelerates to <1 km/h, the
electromagnetic brake will bring the motor
to a stop.
B
B
Fig1154-00020OM
Fig1154-00016OM
