Epever DR3210N-DDS - Naming Rule; Appearance

3
1.2 Naming Rule
1.3 Appearance
❶
Mounting hole sizeΦ5mm
❻
BATT1 terminals
❷
LCD(Refer to chapter 3)
❼
BATT2 terminals
❸
Grounding Terminal
❽
RS485 Communication port
⑵
❹
Remote temperature sensor
⑴
port
❾
AES (signal) output port
⑵
❺
PV terminals
❿
Terminal protection cover
⑴ The controller charges the BATT1 as default (25℃) when it's not connected
to the remote temperature sensor or the temperature sensor is damaged.
