EPH Controls CP4D - P0 8 PIN Lock

43
RFRPD Room Thermostat CP4D
This function allows the user to put a PIN lock on the thermostat.
There are two options available.
‘OPt 01’. The thermostat is fully locked.
‘OPt 02’. This will reduce the functionality of the thermostat.
The user will be able to change the mode between AUTO and OFF.
Set Up the PIN
Press and hold
PROG
and for 5 seconds.
‘P01’ will appear on the screen.
Rotate
clockwise until ‘P08 & PIn’ appears on the screen.
Press
. ‘OFF’ will appear on the screen.
Rotate
to select ON.
Press
. Rotate to select ‘OPt 01’ or ‘OPt 02’.
Press
. ‘0000’ will ash on the screen.
Rotate
to set the value for the rst digit.
Press
to conrm and move to the next PIN digit.
When the last digit of the PIN is set, press
.
P0 8 PIN Lock OFF
