EPH Controls CP4D - To Connect the RFRPD Thermostat to an RF1 B Receiver

59
CP4D
When installing a CP4D, the RFRPD thermostat and the RF1B receiver will
have a pre-established RF connection so it is not necessary to carry out the
RF connection process below.
To connect the RFRPD Thermostat
to an RF1B receiver
On the RF1B receiver:
Hold
Connect
for 3 seconds.
The RF LED will begin to ash.
On the RFRPD thermostat:
Press the connect
button on the side of the thermostat.
The thermostat will show ‘nOE’ followed by ‘---’
Once an RF connection has been established the thermostat will show
‘r01’ on the LCD screen.
Press to nish the process.
The thermostat is now connected to the RF1B receiver.
