RFRPD
OpenTherm® Instructions
Identifying if a receiver is a Hub Receiver:
1. If the Hub LED is illuminated the RF1B is a Hub receiver.
Pairing the RF1B receivers together:
1. Hold
Connect
on the Hub receiver for 3 seconds.
The RF LED will begin to ash.
2. Hold
Connect
on the next receiver to be paired. The RF LED
will ash 3 times and then stop. This receiver is now linked.
3. Repeat this process to pair more, up to a maximum of 6 receivers.
4. Press
Manual
on the hub to return to normal operation.
Once all units have been paired, allow time for the receivers to begin to
communicate and receive OpenTherm® information from the boiler. This
may take approximately 2 – 5 minutes.
Disconnecting the RF1B receiver from other Receivers:
1. Hold
Manual
&
Connect
on the Hub receiver until the Hub LED turns o.
This will clear the connection to the branch receivers.
