Installing Options 119
Chapter 6
Installing Options
Optional Legal-size Paper Support
Installing the Optional Legal-size Paper Support
Align the legal-size paper support with the right side of the paper support and attach it as
shown. You can load up to 60 sheets of plain legal-size paper (up to 20 lb or 75 g/m²).
Do not leave legal-size paper in the rear sheet feeder when you are not printing, or the
sheets may curl.
Optional Duplex Unit (B-300 only)
Installing the Optional Duplex Unit
Follow the steps below to install the duplex unit.
1. Turn off the printer.
2. Press the hooks on both sides of the upper rear printer cover, and then remove the
upper rear printer cover.
To Next Page
