Handling Paper and Other Media | 45
Using the Front Manual Feed Slot
If you want to print on posterboard or other media 31 to 59 mil (0.8 to 1.5
mm) thick, you must use the manual feed slot. This provides a
straight-through paper path. Be sure to allow enough room behind the
printer so the paper is not bent when it feeds into the printing position.
1. Make sure the printer is turned on, then press the l Paper Source
button until the sheet icon
appears on the LCD screen.
2. Press the button to release the paper.
3. Open the top cover.
4. Insert the sheet face-up, above the black rollers.
Note: When the optional
SpectroProofer is
installed, you cannot print
from the front manual
feed slot.
