Epson DS-970 User Manual

4. Open the cover of the pickup roller, and then slide and remove it.
5. Pull down the xture of the roller axis, and then slide and remove the installed pickup rollers.
c
Important:
Do not pull out the pickup roller forcibly. is could damage the inside of the scanner.
User's Guide
Maintenance
108

Epson DS-970 Specifications

General

Optical Resolution	600 dpi
Maximum Scan Speed	85 ppm / 170 ipm
ADF Capacity	100 sheets
Daily Duty Cycle	9, 000 pages
Light Source	LED
Maximum Resolution	1200 dpi
Scan Speed (Color, A4, 300 dpi)	85 ppm / 170 ipm
Scan Speed (Black & White, A4, 300 dpi)	85 ppm / 170 ipm
Document Feeder Capacity	100 sheets
Maximum Document Size	215.9 x 6096 mm
Minimum Document Size	50.8 x 50.8 mm
Scanner Type	Sheetfed
Connectivity	USB 3.0
Supported Media Size	A4, A5, A6, B5
Document Size	Minimum: 50.8 x 50.8 mm; Maximum: 215.9 x 6096 mm
Operating Systems Supported	Windows, macOS
Color Depth	24-bit external
