Installation Guide
76
h
Attach the supplied two markers to the marker positions ( ) ( ) on the projection
screen
Match the positions so that the crosses ( ) for the markers overlap with the points ( ) for the
(
) ( ).
•
Magnetic screens: Place the bottom of the markers onto the screen.
•
Non-magnetic screens: Use the supplied tape to secure the markers. Attach the tape so that the either end of
marker does not come loose off the screen.
Correct Incorrect
c
Do not place anything other than the markers near the projected image during angle
adjustment. If other objects are on the projected image, angle adjustment may not be
performed correctly.
To Next Page
