Installation Guide
42
Attaching the setting plate to the wall plate
a
Insert the hexagonal axis into the setting plate
b
Mount the setting plate to the wall plate
Insert the top of the hexagonal axis into the wall plate, and then insert it into the slot at the bottom.
Caution
•
Do not route the Touch Unit connection cable into the wall. If it is wired into the wall, it cannot be
connected to the Touch Unit.
•
Take care not to trap the cables between the setting plate and wall plate.
To Next Page
