Name Function
G
Audio2 port
• Inputs audio from equipment connected to the
Computer2 port.
• Inputs audio from other devices when projecting
images from the Document Camera connected to the
USB(TypeA) port.
H
Power inlet
Connects the power cord to the projector.
s "From Installation to Projection" p.33
I
RS-232C port
When controlling the projector from a computer, connect
it to the computer with an RS-232C cable. This port is for
control use and should not normally be used.
s "ESC/VP21 Commands" p.79
J
LAN port
Connects a LAN cable to connect to a network.
K
Remote receiver
Receives signals from the remote control.
L
Security slot
The security slot is compatible with the Microsaver
Security System manufactured by Kensington.
s "Anti-Theft Lock" p.70
M
USB(TypeA) port
• Connects a USB memory device or a digital camera and
projects PDFs, movies, or images using PC Free.
s
PC Free Operation Guide
• Ports with a
mark are for the optional Document
Camera. You cannot project using other devices from
this port.
N
USB(TypeB) port
• Connects the projector to a computer via a
commercially available USB cable, and projects the
images on the computer.
s "Projecting with USB Display" p.35
• Connects the projector to a computer via the
commercially available USB cable to use the Wireless
Mouse function.
s
"Using the Remote Control to Operate the
Mouse Pointer (Wireless Mouse)" p.61
Name Function
O
Computer2 port
Inputs image signals from a computer and component
video signals from other video sources.
P
Video port
Inputs composite video signals from video sources.
Q
HDMI port
Inputs video signals from HDMI compatible video
equipment and computers. This projector is compatible
with
HDCP
g
.
s "Connecting Equipment" p.25
Part Names and Functions
14
