31
English
f Use the right adjustment dial to adjust the horizontal rotation
(1) Loosen the screws (x2) in the following figure ( ).
(2) Turn the adjustment dial ( ) to adjust the horizontal rotation ( ).
(3) After you finish making all of the adjustments in steps
e to j, tighten the screws (x2) you
loosened in .
g Use the top adjustment dial to adjust the vertical tilt
(1) Loosen the screw in the following figure ( ).
(2) Turn the adjustment dial ( ) to adjust the vertical tilt ( ).
(3) After you finish making all of the adjustments in steps
e to j, tighten the screw you
loosened in .
To Next Page
