Epson EB-475W Installation Guide

8
Horizontal slide adjustment range
Forward/backward slide adjustment range
45 mm 45 mm
248 mm
By changing the installation position of the 3-axis adjustment unit to the front or back, you can adjust the
installation position of the projector.
When the screen size is less than 70 inches, install it at the position marked with a stamp.
When the screen size is 70 inches or more, install it at the position marked with a stamp.
Arm slide adjustment range
Adjustment from 3-axis adjustment unit installation position
62 mm
