Epson EB-X20 User Manual

Installing the Wireless LAN Unit
Only EB-X21/EB-S21/EB-X17/EB-S17 are supported.
By installing the optional Wireless LAN unit, you can project a computer
screen over a network.
Connect the wireless LAN unit to the projector's USB-A port.
a
• When connecting to the network using wireless LAN, make sure you
make network settings from the Configuration menu.
s "Wireless LAN menu (EB-X21/EB-S21/EB-X17/EB-S17 only)"
p.93
• If you normally leave the wireless LAN unit installed, make sure you
attach the supplied wireless LAN unit cover as a theft deterrent.
• When moving the projector, make sure you remove the wireless
LAN unit and cover for safety reasons.
a
Use a cross-head screwdriver to remove the screw that secures the
wireless LAN unit cover.
b
Connect the wireless LAN unit to the USB-A port.
c
Attach the wireless LAN unit cover, and secure it in place with the
screw.
Connecting Equipment
31

Epson EB-X20 Specifications

General

Projection System	3LCD Technology
LCD Panel	0.55 inch with MLA (D8)
Color Light Output	2, 700 lumen - 1, 890 lumen (economy)
White Light Output	2, 700 lumen - 1, 890 lumen (economy)
Resolution	XGA, 1024 x 768, 4:3
Contrast Ratio	10, 000:1
Lamp	ETORL, 200 W, 5, 000 h durability, 6, 000 h durability (economy mode)
Keystone Correction	Auto vertical: ± 30°, Manual horizontal ± 30°
Projection Ratio	1.48 - 1.77:1
Zoom	Manual, Factor: 1.2
Projection Size	30 inches - 300 inches
Projection Distance Wide/Tele	1.8 m - 2.17 m (60 inch screen)
Projection Lens F Number	1.58 - 1.72
Focal Distance	16.9 mm - 20.28 mm
Focus	Manual
Offset	8:1
USB Display Function	3 in 1: Image / Mouse / Sound
Interfaces	USB 2.0 Type B, RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), VGA in (2x), VGA out, HDMI in, Composite in, Component in (2x), S-Video in, RGB in (2x), Stereo mini jack audio out, Stereo mini jack audio in (2x), Cinch audio in
Energy Use	270 W, 223 W (economy), 0.47 W (standby)
Dimensions Single Carton	363 x 397 x 160 mm
Carton Weight	4.12 Kg
