a
If Password Protect is already activated, you must enter the
password.
If the password is entered correctly, the Password Protect
setting menu is displayed.
s "Entering the Password" p.66
When the password is set, stick the password protect sticker
in a visible position on the projector as a further theft
deterrent.
s Password Protect Sticker
b
Select the type of Password Protect you want to set, and then
press the [
] button.
c
Select On, and then press the [ ] button.
Press the [Esc] button, the screen displayed in step 2 is displayed
again.
d
Set the password.
(1)
Select Password, and then press the [
] button.
(2)
When the message "Change the password?" is displayed, select Yes and
then press the [
] button. The default password is set to "0000". Change
this to your own desired Password. If you select No, the screen displayed
in step 2 is displayed again.
(3) While holding down the [Num] button, enter a four digit number using
the numeric buttons. The number entered is displayed as "* * * *". When
you enter the fourth digit, the confirmation screen is displayed.
Remote control
(4) Re-enter the password.
"The message Password accepted." is displayed.
If you enter the password incorrectly, a message is displayed prompting
you to re-enter the password.
Entering the Password
When the password entry screen is displayed, enter the password using the
remote control.
While holding down the [Num] button, enter the password by pressing the
numeric buttons.
Security Functions
66

Table of Contents

Other manuals for Epson EB-X20

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-X20 and is the answer not in the manual?

Epson EB-X20 Specifications

General IconGeneral
Projection System3LCD Technology
LCD Panel0.55 inch with MLA (D8)
Color Light Output2, 700 lumen - 1, 890 lumen (economy)
White Light Output2, 700 lumen - 1, 890 lumen (economy)
ResolutionXGA, 1024 x 768, 4:3
Contrast Ratio10, 000:1
LampETORL, 200 W, 5, 000 h durability, 6, 000 h durability (economy mode)
Keystone CorrectionAuto vertical: ± 30°, Manual horizontal ± 30°
Projection Ratio1.48 - 1.77:1
ZoomManual, Factor: 1.2
Projection Size30 inches - 300 inches
Projection Distance Wide/Tele1.8 m - 2.17 m (60 inch screen)
Projection Lens F Number1.58 - 1.72
Focal Distance16.9 mm - 20.28 mm
FocusManual
Offset8:1
USB Display Function3 in 1: Image / Mouse / Sound
InterfacesUSB 2.0 Type B, RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), VGA in (2x), VGA out, HDMI in, Composite in, Component in (2x), S-Video in, RGB in (2x), Stereo mini jack audio out, Stereo mini jack audio in (2x), Cinch audio in
Energy Use270 W, 223 W (economy), 0.47 W (standby)
Dimensions Single Carton363 x 397 x 160 mm
Carton Weight4.12 Kg
