Base
Name Function
A
Cable wiring slot
(bottom)
Remove the cover, and pass the cable down through here.
s "Attaching and Removing the Interface Cover"
p.28
B
Front feet
s "Adjusting the tilt of the projected image (for normal
installment)" p.36
C
Rear feet
s "Adjusting the tilt of the projected image (for normal
installment)" p.36
Interface
You can access the following ports by removing the interface cover. For
information on how to remove the interface cover and connect video
equipment, see the following.
s "Attaching and Removing the Interface Cover" p.28
s "Connecting Equipment" p.41
Name Function
A
SDI input port
(For EB-Z10005U/EB-
Z10000U/EB-Z9875U/
EB-Z9870U only)
Inputs SDI signals from video equipment.
B
BNC input port
For analog RGB signals from a computer and component
video signals from other video sources.
C
Video input port
For composite video signals from video sources.
Part Names and Functions
16
