Epson EH-TW5825 User Manual

Contents
4
Adjust using the gamma adjustment graph . . 39
Viewing the Image at the Saved Image
Quality (Memory Function) . . . . . . . . . . . 40
Saving a Memory ....................... 40
Loading, Deleting, and Renaming a Memory . . . 41
Useful Functions
Using the HDMI Link Function ........ 42
HDMI Link Function ..................... 42
HDMI Link Settings ...................... 42
Connecting ........................... 43
Configuration Menu
Configuration Menu Functions ........ 44
Configuration Menu Operations ............ 44
Configuration Menu Table................ 45
Image menu ........................45
Signal menu ........................ 46
Settings menu ....................... 46
Extended menu ...................... 49
Info menu .......................... 50
Reset menu ......................... 50
Troubleshooting
Problem Solving ..................... 51
Reading the Indicators ................... 51
Indicator status during an error/warning....51
Indicator status during normal operation . . . . 53
When the Indicators Provide No Help........54
Check the problem .................... 54
Problems relating to images ............. 55
Noise problems ...................... 58
Problems when projection starts .......... 58
Problems with the remote control ......... 59
Problems with the control panel .......... 59
Problems with HDMI .................. 59
Bluetooth device problems ..............60
Problems with a streaming media player . . . . 61
Maintenance
Maintenance ........................ 62
Cleaning the Parts ...................... 62
Cleaning the air filter .................. 62
Cleaning the main unit ................. 63
Cleaning the lens ..................... 64
Replacement Periods for Consumables.......64
Air filter replacement period .............64
Lamp replacement period .............. 64
Replacing Consumables ..................65
Replacing the air filter .................65
Replacing the lamp ...................65
Resetting lamp hours ..................67
Disconnecting a Streaming Media Player......69
Appendix
Optional Accessories and
Consumables ........................ 70
Optional Items ......................... 70
Consumables .......................... 70
Supported Resolutions ............... 71
PC .................................. 71
SD ................................. 71
HD ................................. 71
Specifications ....................... 73
EH-TW5825/EH-TW5705 .................. 73
Appearance ......................... 75
List of Safety Symbols ................ 76
Glossary ............................ 78
General Notes ....................... 79
Warning Labels ........................ 80
Disposal ............................. 80
General Notice ......................... 81

Epson EH-TW5825 Specifications

General

Matrix size	0.61 \
Heat dissipation	1009.8 BTU/h
Number of colors	1.07 billion colors
Native aspect ratio	16:9
Projection distance	2.35 - 3.82 m
Vertical scan range	192 - 240 Hz
Projection technology	3LCD
Contrast ratio (typical)	70000:1
Screen size compatibility	30 - 300 \
Projector native resolution	1080p (1920x1080)
Keystone correction, vertical	-30 - 30 °
Projector brightness (economic mode)	1780 ANSI lumens
3D	No
Full HD	Yes
Video processing	10 bit
Video color modes	Cinema, Dynamic, Natural, Bright cinema
Analog signal format system	Not supported
Lamp type	UHE
Lamp power	200 W
Light source type	Lamp
Service life of light source	4500 h
Service life of light source (economic mode)	7500 h
Throw ratio	1.33 - 2.00:1
Focal length range	18.2 - 29.2 mm
Aperture range (F-F)	1.51 - 1.99
Vertical lens shift range	-60 - 60 %
Noise level	36 dB
Country of origin	Philippines
Operating system installed	Android
Noise level (economic mode)	28 dB
Placement	Ceiling, Desktop
Product color	White
Market positioning	Home cinema
Cable lock slot type	Kensington
RMS rated power	10 W
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	297 W
Power consumption (economy mode)	227 W
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	66 pc(s)
Harmonized System (HS) code	85286200
HDMI version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0

Weight and Dimensions

Depth	315 mm
Width	309 mm
Height	122 mm
Weight	3800 g
Package depth	410 mm
Package width	380 mm
Package height	180 mm
Package weight	5280 g
