Appendix
75
Appearance
Units: mm
46.1 *
122
309
a
b
102.5
*1: EH-TW5825
*2: EH-TW5705
44.8 *
aCenter of lens
b Distance from center of lens to suspension bracket fixing point
308
107.5
315 214.9
95.5
142.4 99.6
LENS
140.5 132.5
