Adjusting the Image
36
Abs. Color Temp.
You can adjust the overall tint of the image. Make adjustments if the image is a little too blue or too red and
so on.
The menu is displayed in the following order.
Image - Abs. Color Temp.
Use the
buttons to make adjustments.
Blue tints grow stronger as the value is increased, and red
tints grow stronger as the value is reduced.
c
Press the button to return the adjustments to their default values.
Skin Tone
You can adjust the skin tone. Make adjustments if the skin tone is too red or too green and so on.
The menu is displayed in the following order.
Image - Skin Tone
Use the
buttons to make adjustments.
The image becomes greener when set to the right (positive)
and redder when set to the left (negative).
c
Press the button to return the adjustments to their default values.
