Appendix
88
Specifications
Product name
EH-TW9000W EH-TW9000 EH-TW8000
Appearance (not including adjustable foot)
466 (W) x 140 (H) x 395 (D) mm
Panel Size
0.74" wide
Display method
Polysilicon TFT active matrix
Resolution
1920 (W) x 1080 (H) x 3
Scanning Fre-
quency
Digital
Pixel Clock: 13.5 - 148.5 MHz
Horizontal: 15.6 - 67.5 kHz
Vertical: 24 - 60 Hz
Analog
Pixel Clock: 13.5 - 157.5 MHz
Horizontal: 15.6 - 91.2 kHz
Vertical: 50 - 85 Hz
Focus adjustment
Manual
Zoom adjustment
Manual (approx. 1 to 2.1)
Lamp (light source)
UHE lamp 230 W, Model No.: ELPLP69
Power supply
100 to 240 V AC ±10%, 50/60 Hz, 3.7 - 1.6 A
Power con-
sumption
100 to 120 V area
Operating: 364 W
Standby power consumption: 0.27 W
Standby power consumption: 5.6 W
*
220 to 240 V area
Operating: 348 W
Standby power consumption: 0.37 W
Standby power consumption: 6.3 W
*
Operating altitude
Altitude 0 to 2286 m
Operating temperature
+5 to 35°C (No condensation)
Storage temperature
-10 to +60°C (No condensation)
Mass
Approx. 8.5 kg Approx. 8.3 kg Approx. 8.3 kg
Connectors
Component port x 1, 3RCA pin jack
PC port x 1, Mini D-Sub15-pin (female) blue
HDMI port x 2, HDMI
For HDCP, For CEC signals
Video port x 1, RCA pin jack
RS-232C port x 1, D-sub 9-pin (male)
Trigger out port x 1, 3.5 mm mini jack
External 3D IR port x 1, RJ45
*
For EH-TW9000W, only when the following requirements are met.
Settings - HDMI Link - Power On Link is set to Bidirectional or Device -> PJ
