Introduction
9
Specifications
ELPMB67
External dimensions when assembled 330 × 124 × 356 mm
Mass Approx. 5.7 kg
Load-bearing capacity 40 kg
Adjustment
range
Vertical tilt angle -15 to 5°
Horizontal tilt angle ±5°
Horizontal rotation angle ±5°
Front/back slide ±36 mm
Vertical tilt angle Horizontal tilt angle
Horizontal rotation angle Front/back slide
ELPFP15
External dimensions when
assembled
Φ270 × 352 mm
Mass Approx. 4.4 kg
Adjustment range 460 to 680 mm
(Distance between adjustment holes: 20 mm)
