Installation Method
22
b
Loosen the screws on the wire clip and thread the safety wire through
c
Thread the safety wire through the hole in the projector mount
Make sure the end of the safety wire is threaded through the wire clip.
d
Adjust the length of the safety wire and tighten the screws on the wire clip to secure it in
place
Make sure the safety wire is as taut as possible.
If the end of the safety wire is too long, trim it to the appropriate length.
e
Follow steps 1 to 4 to attach the rest of the safety wires
Connecting the Ceiling Mount to the projector with a wire
Use the safety wire set (for projector installation) supplied.
Installing
The points through which the safety wire is threaded vary depending on the projector. See the User's Guide
for the projector you are using.
The illustrations in the following procedure are an example only.
To Next Page
