Installation Method
11
Preparation
Checking the Installation Location
Before installing, check the projection distance to the screen and make sure the projector is in the correct
position.
The projection distance to the screen varies depending on the projector. See the User's Guide supplied with
the projector you are using.
Attaching the projector mount to the projector
Attaching the projector mount
Attach the projector mount to the bottom of the projector using the supplied M6 x 15 mm bolts (x4).
Make sure that the
mark on the projector mount is facing the lens side of the projector.
Preparing the Suspension Adapter (when Using ELPFP15)
c
When using the veneer plate supplied, pass the plate over the ceiling mount pipe in advance.
Attaching the veneer plate makes the gap between the installation surface and the Suspension
Adapter less noticeable.
To Next Page
