Table A-12. CN209 Pin Assignments
Pin No. Signal Name I/O Description
1
+24 V
—
+24 VDC
2
FEED2
O
Lower cassette solenoid on
3
NC
—
No connected
4
+5V
—
+5 VDC
5
GND1
—
Ground
6
PE2
I
Lower cassette paper empty
7
PSIZ0
8
PSIZ1
9
PSIZE2
10
CHECK1
11
CHECK2
12
CHECK3
Table A-13. CN210 Pin Assignments
Pin No. Signal Name I/O Description
1
NC
—
Not connected
2
+24V
—
+24 VDC
3
GND2
—
Ground
4
+5V
—
+5 VDC
5
P-CTL
O
Polygon motor control
Table A-14. CN211 Pin Assignments
Pin No. Signal Name I/O Description
1
+24V
—
+24 VDC
2
FAN
O
Fan control
Appendix EPL-5500 Service Manual
A-10 Rev. A
