3.1.4 Service Checks after Repair
Check the repaired unit using the following list on completion of servicing.
Table 3-3. Checks after Repair
Item Location Checkpoint Check
Operation Control panel Do all LEDs and button function normally?
Heater lamp Does the heater lamp turn on normally?
Test print
(status sheet)
Is the test print performed normally?
Data print Does data print in all modes?
Adjustment Print position Is the gap between the top edge of the paper and
the horizontal line in the status sheet print exactly
29.6 mm (1.17 inch).
ROM version Is it the latest version?
Cleaning Is toner and dust removed from the paper path?
Is the paper take-up roller cleaned?
Is the roller in the fusing unit cleaned?
Is the outer surface of the printer clean?
Packing Is the consumable removed from the printer?
Is the unit packed securely?
Are accessories packed also?
EPL-5500 Service Manual Disassembly and Assembly
Rev. B 3-3
