Epson LX-350 User Manual

IBM character table (IBM PPDS)
*3
Table2, Table1
Power off timer Off, 1 hours, 2 hours, 4 hours, 8 hours, 12 hours
*1
Settings with bold weight mean the standard factory settings. Settings may vary depending on the country.
*2
The options available vary depending on the country.
*3
These settings take effect only when IBM PPDS emulation is selected.
Page length for tractor
This setting allows you to set the page length (in inches) for continuous paper.
Skip over perforation
This feature is available only when continuous paper is selected. When you select On, the printer provides a one-inch (25.4
mm) margin between the last line printed on one page and the first line printed on the next page. Because the program
margin settings in most applications override margin settings made from the control panel, you should use this setting only if
you cannot set your top and bottom margins using your application.
Auto tear off
When auto tear off is on and you are using continuous paper with the push tractor, the printer automatically advances the
paper perforation to the tear-off position, where you can easily tear off the printed pages. When the printer receives the next
print job, it automatically moves the unused paper back to the top-of-form position and starts printing, so you can use all of
the next page.
Auto tear off is available under the following conditions.
No print data is sent for more than three seconds after entering a page break by holding down the LF/FF button.
No print data is sent for more than three seconds after sending an FF command.
When auto tear off is off, you need to move the perforation to the tear-off position by pressing the control panel button. See
Using the Tear Off button for more information.
Auto line feed
When auto line feed is on, the printer accompanies each carriage return (CR) code received with a line feed code, and the
print position moves to the next line. If the printer adds an extra line after every carriage return, select Off.
Print direction
You can select bidirectional printing (Bi-D) or unidirectional printing (Uni-D). Printing is normally bidirectional for faster
printing; however, unidirectional printing allows for precise vertical printing alignment, which is useful for printing graphics.
Software
When you select ESC/P, the printer operates in the EPSON ESC/P mode. When you select IBM PPDS, the printer emulates an
IBM printer.
0 slash
The zero character has a slash ( ) when is selected. There is no slash (0) when 0 is selected. The slash allows you to easily
distinguish between the uppercase letter O and a zero.
I/F (interface) mode

Epson LX-350 Specifications

General

print speed (draft high-speed)	347 cps (10 cpi), 357 cps (12 cpi), 390 cps (15 cpi)
print speed (draft high-speed condensed)	383 cps (17 cpi), 298 cps (20 cpi)
print speed (draft)	260 cps (10 cpi), 312 cps (12 cpi), 223 cps (15 cpi)
print speed (draft condensed)	222 cps (17 cpi), 260 cps (20 cpi)
print speed (draft in bold)	130 cps (10 cpi)
print speed (near letter quality)	65 cps (10 cpi), 78 cps (12 cpi), 55 cps (15 cpi), 47 cps (17 cpi), 56 cps (20 cpi)
column width	80 cpl (10 cpi), 96 cpl (12 cpi), 120 cpl (15 cpi), 137 cpl (17 cpi), 160 cpl (20 cpi)
cut sheets width	3.9 ~ 10.1" (100 ~ 257 mm)
cut sheets length	3.9 ~ 14.3" (100 ~ 364 mm)
cut sheets thickness	0.0025 ~ 0.0055" (0.065 ~ 0.14 mm)
multiple forms width	3.9 ~ 10.1" (100 ~ 257 mm)
multiple forms length	3.9 ~ 14.3" (100 ~ 364 mm)
multiple forms thickness	0.0047 ~ 0.015" (Total) (0.12 ~ 0.39 mm)
envelopes (No.6) width	6.5" (165 mm)
envelopes (No.6) length	3.6" (92 mm)
envelopes (No.6) thickness	0.0063 ~ 0.0205" (Total) (0.16 ~ 0.52 mm)
envelopes (No.10) width	9.5" (241 mm)
envelopes (No.10) length	4.1" (105 mm)
envelopes (No.10) thickness	0.0063 ~ 0.0205" (Total) (0.16 ~ 0.52 mm)
continuous forms width	4.0 ~ 10.0" (101.6 ~ 254.0 mm)
continuous forms length (per sheet)	4.0 ~ 22.0" (101.6 ~ 558.8 mm)
continuous forms thickness	0.0025 ~ 0.015" (Total) (0.065 ~ 0.39 mm)
paper roll holder width	8.5" (216 mm)
paper roll holder thickness	0.0028 ~ 0.0035" (0.07 ~ 0.09 mm)
copies	1 original + 4 copies
format space between lines	1/6" (4.23 mm) or programmable in increments of 1/216" (0.118 mm)
voltage	AC 120 V / AC 220 - 240 V
frequency	50 Hz / 60 Hz
power consumption	27 W (ISO/IEC 10561 Letter pattern)
power consumption in sleep mode	Approx. 1.1 W
power consumption in powered off mode	0 W
power consumption in auto off mode	Approx. 0.3W
temperature	41 ~ 95°F
humidity	10 ~ 80% RH
mean time before failure	10, 000 POH (at 25% duty)
print head life	400 million strokes/wire
sound level	Approx. 53 dB(A) (ISO 7779 standard)
interfaces	Bidirectional parallel (IEEE-1284), USB high speed (ver 2.0), Serial
input buffer	128KB

Weight and Dimensions

width	14.25" (13.7" without knob)
depth	10.83"
height	6.06"
weight	9.04 lb
