Epson PowerLite S5 Series User Manual

36 Projecting
If you’re using a Macintosh laptop with OS X:
You may need to set up your system to display on the projector screen
as well as the LCD screen. Follow these steps:
1. From the Apple menu, select
System Preferences, then click
Display or Displays.
2. Select VGA Display or Color LCD, click Arrange or
Arrangement, and make sure Mirror Displays is checked.
Click here
Select Mirror
Displays

Epson PowerLite S5 Series Specifications

General

Resolution	800 x 600 (SVGA)
Contrast Ratio	400:1
Weight	2.7 kg (6.0 lbs)
Projection System	3LCD, 3-chip technology
Lamp Type	170 W UHE
Lamp Life	3000 hours (Normal Mode)
Zoom Ratio	1.35x
Projection Size	30" to 300"
Input Ports	Composite Video (RCA), S-Video (Mini DIN 4-pin), Audio (Stereo Mini Jack), VGA (HD D-sub 15-pin)
Output Ports	VGA (HD D-sub 15-pin)
Noise Level	37 dB (Normal Mode), 30 dB (Low Brightness Mode)
