Epson PowerLite S5 Series User Manual

Maintenance and Transportation 77
2. If the projector has been on, allow it to cool down for at least an
hour (or until the lamp is cool).
3. Use the screwdriver included with the replacement lamp to loosen
the screw holding the lamp cover (the lamp cover is located on top
of the projector).
4. Slide the cover out, then lift it off.
5. Use the screwdriver to loosen the two screws holding the lamp in
place. (You can’t remove the screws.)
6. Hold the lamp as shown and pull it straight out.
Don’t remove
these screws
note
The lamp(s) in this
product contain mercury.
Please consult your state and
local regulations regarding
disposal or recycling. Do not
put in the trash.

Epson PowerLite S5 Series Specifications

General

Resolution	800 x 600 (SVGA)
Contrast Ratio	400:1
Weight	2.7 kg (6.0 lbs)
Projection System	3LCD, 3-chip technology
Lamp Type	170 W UHE
Lamp Life	3000 hours (Normal Mode)
Zoom Ratio	1.35x
Projection Size	30" to 300"
Input Ports	Composite Video (RCA), S-Video (Mini DIN 4-pin), Audio (Stereo Mini Jack), VGA (HD D-sub 15-pin)
Output Ports	VGA (HD D-sub 15-pin)
Noise Level	37 dB (Normal Mode), 30 dB (Low Brightness Mode)
