Epson SC-T5200 Series User Manual

❏ To delete a group (folder), click Delete
Group.
❏ Drag and drop unnecessary items to Not
Display.
Note:
When Delete Group is performed, the group
(folder) is deleted, however the items in the deleted
group (folder) remain.
D
Click Save.
Overview of the Utility
Tab
The printer driver's Utility tab provides access to the
following.
Nozzle Check
This function prints a nozzle check pattern to check if
the print head nozzles are clogged. If you see banding or
gaps in the print outs, perform head cleaning to clear
any clogged nozzles.
U “Cleaning the print head” on page 166
Head Cleaning
If you see banding or gaps in the print outs, perform
head cleaning. Cleans the surface of the print head to
improve the print quality.
U “Cleaning the print head” on page 166
Print Head Alignment
If the print results appear grainy or out of focus, perform
Print Head Alignment. The Print Head Alignment
function corrects print head gaps.
U “Minimizing Print Misalignments (Head
Alignment)” on page 167
EPSON Status Monitor 3
You can check the printer's status, such as the remaining
ink level and error messages, on the computer's screen.
When roll paper is loaded on Roll 1 or Roll 2 of the
SC-T7200D Series/SC-T5200D Series, you can also
check which is selected an operational object (in use).
SC-T7200 Series/SC-T5200 Series/SC-T3200 Series/SC-T7200D Series/SC-T5200D Series User's Guide
Tips for Using the Printer Driver(Windows)
124

Epson SC-T5200 Series Specifications

General

Memory	1 GB
Print Resolution	2880 x 1440 dpi
Print Speed	28 seconds per A1 sheet
Paper Sizes	A0, A1, A2, A3+, A3, A4
Print Margin Roll	3 mm (top, side, bottom)
Interfaces	USB 2.0, Ethernet
Hard Disk	320 GB
Acoustic Noise	50 dB(A)
Dimensions	1405‎ x 813 x 1128 mm (Width x Depth x Height)
Ink Colors	Cyan, Magenta, Yellow, Black
Media Types	Plain paper, Photo paper
Operating Systems	Mac OS X 10.6.8 or later
