Epson SC-T5200 Series User Manual

After wrapping the paper around the core,
ensure that paper around the core is sufficiently
loose.
H
Set the Auto switch to Backward.
Removing Paper from the Auto
Take-up Reel Unit
This section describes how to remove paper from the
auto take-up reel unit.
!
Caution:
Removing paper from the auto take-up reel unit
requires two workers, one on each end of the roll.
A single worker working alone could drop the roll,
resulting in injury.
Buttons that are used in the following settings
A
Set the Auto switch to Off.
B
Cut the paper and take it up until it is all on the
auto take-up reel unit roll core.
U “Manual cut method” on page 33
After cutting the paper, support the end to
prevent the printed surface touching the floor;
continue to support the paper until it is all taken
up. Keep the Manual switch pressed in the
take-up direction (either Forward or Backward).
SC-T7200 Series/SC-T5200 Series/SC-T3200 Series/SC-T7200D Series/SC-T5200D Series User's Guide
Basic Operations
55

Epson SC-T5200 Series Specifications

General

Memory	1 GB
Print Resolution	2880 x 1440 dpi
Print Speed	28 seconds per A1 sheet
Paper Sizes	A0, A1, A2, A3+, A3, A4
Print Margin Roll	3 mm (top, side, bottom)
Interfaces	USB 2.0, Ethernet
Hard Disk	320 GB
Acoustic Noise	50 dB(A)
Dimensions	1405‎ x 813 x 1128 mm (Width x Depth x Height)
Ink Colors	Cyan, Magenta, Yellow, Black
Media Types	Plain paper, Photo paper
Operating Systems	Mac OS X 10.6.8 or later
