Epson SC-T5200 Series User Manual

U “Using Epson Printer Utility 4” on page 127
A
Click Head Cleaning from the Utility tab in the
printer driver's Properties (or Printing
preferences) screen.
B
Click Start.
Head cleaning starts and it takes about one to ten
minutes.
C
Click Print Nozzle Check Pattern.
Confirm the nozzle check pattern.
If any segments are missing in the nozzle check
pattern, click Clean.
From the printer
Buttons that are used in the following settings
A
Confirm that the printer is ready to print. Press
the " button.
The Maintenance menu will be displayed.
B
Press the d/u buttons to highlight Head
Cleaning and press the Z button.
You will be prompted to choose nozzle rows.
C
Select nozzle rows for cleaning.
Press the l/r buttons to highlight numbers
corresponding to check patterns with faint or
missing segments and press the d/u button to
select.
You can select multiple nozzle rows.
To select all nozzles, place a check in the box on
the left.
D
Pressing the Z button displays a confirmation
message. Press the Z button to start head
cleaning.
A confirmation message is displayed when
cleaning is complete.
E
To print a check pattern and check the status of
the clog, press the d/u buttons to highlight
Nozzle Check and press the Z button.
To exit without performing a nozzle check,
highlight Exit and press the Z button.
Minimizing Print Misalignments
(Head Alignment)
Because there is a small distance between the print head
and paper, misalignment may occur due to humidity or
temperature, the inertial force of the print head's
movements, or by moving the print head
bidirectionally. This may result in grainy prints or lines
that are incorrectly placed. When this happens, perform
Head Alignment to correct the print misalignment.
Although Head Alignment can be performed from the
computer or the printer, the alignment procedures
differ as explained below.
❏ From the printer
Head alignment can be performed automatically or
manually.
In auto adjustment, the sensor reads the adjustment
pattern while it is printing, and automatically
SC-T7200 Series/SC-T5200 Series/SC-T3200 Series/SC-T7200D Series/SC-T5200D Series User's Guide
Maintenance
167

Epson SC-T5200 Series Specifications

General

Memory	1 GB
Print Resolution	2880 x 1440 dpi
Print Speed	28 seconds per A1 sheet
Paper Sizes	A0, A1, A2, A3+, A3, A4
Print Margin Roll	3 mm (top, side, bottom)
Interfaces	USB 2.0, Ethernet
Hard Disk	320 GB
Acoustic Noise	50 dB(A)
Dimensions	1405‎ x 813 x 1128 mm (Width x Depth x Height)
Ink Colors	Cyan, Magenta, Yellow, Black
Media Types	Plain paper, Photo paper
Operating Systems	Mac OS X 10.6.8 or later
