Epson SC-T5200 Series User Manual

Displays the Maintenance menu, which is used for
nozzle checks and head cleaning.
U “Adjusting the Print Head” on page 165
L
Wbutton (pause/cancel button)
❏ The printer enters pause status if this is pressed while
printing. To release the pause status, press the W
button again, or select Pause Cancel on the screen
and then press the Z button. To cancel print jobs
being processed, select Job Cancel on the screen and
then press the Z button.
❏ Pressing this button while a menu or help is displayed
closes the menu or help and returns the printer to
ready status.
M
)button (Feed/Cut Media button)
❏ This button is used with roll paper only. If the printer is
loaded with cut sheets or poster board, pressing this
button will have no effect.
❏ It is used to manually cut roll paper using the built-in
cutter.
U “Manual cut method” on page 33
❏ If printing is not currently in progress and the printer is
loaded with roll paper, you can feed paper ahead by
pressing first this button and then the d button. Press
the u button to rewind. Keep the d button pressed to
feed the paper up to 3 m. Keep the d button pressed to
rewind the paper up to 20 cm.
When the u button is used to rewind roll paper, the
paper will pause when the end of the roll reaches the
starting print position. Release the button and then
press it again to resume.
Screen View
A Message
Displays the printer’s status, operation, and error
messages.
U “What to do When a Message is Displayed” on
page 177
B Tabs/Info Display Area
The tab/info display area contains the seven tabs
listed below.
Use the l/r buttons to select a tab.
Information on the selected tab appears in the info
display area.
,
: The Print Queues Tab
Print job information appears in the info
display area.
When you press the Menu button, the Print
Queues menu appears.
U “Print Queues menu” on page 139
The Info Display Area
The name of the job being printed appears
when the printer driver is used.
If an optional hard disk unit or Adobe
PostScript 3 Expansion Unit is installed, it also
shows the number of held jobs, if any.
SC-T7200 Series/SC-T5200 Series/SC-T3200 Series/SC-T7200D Series/SC-T5200D Series User's Guide
Introduction
15

Epson SC-T5200 Series Specifications

General

Memory	1 GB
Print Resolution	2880 x 1440 dpi
Print Speed	28 seconds per A1 sheet
Paper Sizes	A0, A1, A2, A3+, A3, A4
Print Margin Roll	3 mm (top, side, bottom)
Interfaces	USB 2.0, Ethernet
Hard Disk	320 GB
Acoustic Noise	50 dB(A)
Dimensions	1405‎ x 813 x 1128 mm (Width x Depth x Height)
Ink Colors	Cyan, Magenta, Yellow, Black
Media Types	Plain paper, Photo paper
Operating Systems	Mac OS X 10.6.8 or later
