Epson SC-T5200 Series User Manual

Item Description
Roll End Option Continue Select the action to perform for a roll after replacement: print the
remaining data (Continue) / do not print (Stop Printing) / print
again from the beginning (Reprint).
Stop Printing
*
Reprint
*3
Auto Loading
*1
On
*
Normally, leave the setting at On.
If you experience problems with automatic loading when you use
commercially available paper because of lack of tension,
slipperiness, extremely large curls, or other problems, set to Off.
Remove all paper before configuring this setting. If paper is
loaded, the setting cannot be changed.
While the setting is Off, the Roll 2 unit cannot be used.
Off
Roll Switch Setting
*1
Auto
*
Select the action to take when the roll currently in use is under the
following conditions: automatically switch between Roll 1 and Roll
2 and print (Auto) / print fixed to Roll 1 (Roll 1)/print fixed to Roll 2
(Roll 2).
❏ The roll is finished, and there is data still to be printed.
❏ The printer predicts that there is not enough roll paper
remaining, and printing cannot be completed.
❏ The print margin will be large for the width of the print job.
When the setting is Auto, the roll is switched according to the Roll
Switch Condition setting.
Roll 1
Roll 2
SC-T7200 Series/SC-T5200 Series/SC-T3200 Series/SC-T7200D Series/SC-T5200D Series User's Guide
Using the Control Panel Menu
147

Epson SC-T5200 Series Specifications

General

Memory	1 GB
Print Resolution	2880 x 1440 dpi
Print Speed	28 seconds per A1 sheet
Paper Sizes	A0, A1, A2, A3+, A3, A4
Print Margin Roll	3 mm (top, side, bottom)
Interfaces	USB 2.0, Ethernet
Hard Disk	320 GB
Acoustic Noise	50 dB(A)
Dimensions	1405‎ x 813 x 1128 mm (Width x Depth x Height)
Ink Colors	Cyan, Magenta, Yellow, Black
Media Types	Plain paper, Photo paper
Operating Systems	Mac OS X 10.6.8 or later
