Epson SC-T5200 Series User Manual

Guide positioned for other sizes of paper
Horizontal position
A
Use the top stack guide switch lever to raise the
top stack guide.
B
Lift the guide up, and then lower it lightly.
Note:
If the standard position is erroneously set instead of
the horizontal position, lift the guide up, and then
lower it while pushing lightly.
SC-T7200 Series/SC-T5200 Series/SC-T3200 Series/SC-T7200D Series/SC-T5200D Series User's Guide
Basic Operations
48

Epson SC-T5200 Series Specifications

General

Memory	1 GB
Print Resolution	2880 x 1440 dpi
Print Speed	28 seconds per A1 sheet
Paper Sizes	A0, A1, A2, A3+, A3, A4
Print Margin Roll	3 mm (top, side, bottom)
Interfaces	USB 2.0, Ethernet
Hard Disk	320 GB
Acoustic Noise	50 dB(A)
Dimensions	1405‎ x 813 x 1128 mm (Width x Depth x Height)
Ink Colors	Cyan, Magenta, Yellow, Black
Media Types	Plain paper, Photo paper
Operating Systems	Mac OS X 10.6.8 or later
