Epson surecolor p5000 User Manual

150
1. Load roll paper or cut sheet paper in this size or larger: A4 (8.3 × 11.7 inches [210 × 297 mm]).
2. Make sure the correct paper type and paper thickness are selected. Use plain paper or transparent
or colored paper for manual print head alignment.
3. Press the Black ink/maintenance button.
4. Press the down arrow button to select Head Alignment and press the right arrow button.
5. Press the down arrow button to select Alignment and press the right arrow button.
6. Select Manual and press the right arrow button.
7. Press the up or down arrow button to select one of the following options:
• Uni-D aligns each color for uni-directional printing based on Light Cyan. You should choose this
option first.
• Bi-D 2-color aligns each color for bi-directional printing based on Light Cyan and Vivid Light
Magenta. You should choose this option second.
• Bi-D All aligns each color for bi-directional printing based on all colors. You should choose this
option last if you are not satisfied with the previous adjustment results .
8. Press the OK button.
The alignment sheet prints.
Note: When aligning on cut sheet paper, the alignment sheet is printed across multiple pages. Once
the first sheet prints, load the next piece of paper.

Epson surecolor p5000 Specifications

General

Display	LCD
Product color	Black
Built-in display	Yes
Sound pressure level (printing)	47 dB
Print technology	Inkjet
Maximum resolution	2880 x 1440 DPI
Page description languages	ESC P
Media thickness	1.5 mm
Roll top margin	3 mm
Maximum print size	-
Power consumption (standby)	20 W
Power consumption (typical)	52 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	-20 - 40 %
Operating relative humidity (H-H)	45 - 60 %
Maximum input capacity	250 sheets
USB connector	USB Type-A
USB 2.0 ports quantity	1

Weight and Dimensions

Depth	766 mm
Width	863 mm
Height	405 mm
