Epson surecolor p5000 User Manual

42
Loading Cut Sheets in the Front Manual Feeder
Use the front manual feeder to load one cut sheet at a time up to 0.06 inch (1.5 mm) thick.
1. Make sure the printer is turned on.
2. On the control panel, press the paper source button.
3. Press the down arrow button to select Cut Sheet, and press the OK button.
4. Press the load paper button to release the pressure roller.
5. Insert paper with the printable side up over the black roller in the front manual feeder as shown.
6. Look through the printer window and make sure the paper is inserted under the gray roller inside the
printer.

Epson surecolor p5000 Specifications

General

Display	LCD
Product color	Black
Built-in display	Yes
Sound pressure level (printing)	47 dB
Print technology	Inkjet
Maximum resolution	2880 x 1440 DPI
Page description languages	ESC P
Media thickness	1.5 mm
Roll top margin	3 mm
Maximum print size	-
Power consumption (standby)	20 W
Power consumption (typical)	52 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	-20 - 40 %
Operating relative humidity (H-H)	45 - 60 %
Maximum input capacity	250 sheets
USB connector	USB Type-A
USB 2.0 ports quantity	1

Weight and Dimensions

Depth	766 mm
Width	863 mm
Height	405 mm
