APPENDIX C Interfaces
1. Specifications (RS-232C compatible)
Data transmission:
Serial
Synchronization:
Asynchronous
Handshaking:
DTR/DSR or XON/XOFF control
(selected by DIP switch)
Signal level: MARK =
-3 to -15V Logic “1”
SPACE = +3 to +15V Logic “0”
Baud rates:
110, 150, 300, 600, 1200, 2400, 4800, 9600 bps
Data length:
7 or 8 bits
Parity:
None, even or odd
Stop bits:
1 or more
Connector:
D-SUB25 (female connector) or equivalent
-52-
