Epson TM-H5000II series Development Guide

Version 3.00 Feb. 2019
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-H5000II/TM-U590)
19
3.9 Printable bitmap types and sizes
The TM-H5000II/TM-U590 support the following bitmap commands. For the detail,
please refer to the corresponding part of the Section 3 of “EPSON OPOS ADK
MANUAL
APPLICATION DEVELOPMENT GUIDE POSPrinter (TM Series)”. The
allowance ranges for bitmaps are as follows.
z TM-H5000II
Bitmap command type Allowance range
x (dot) y (dot) xy
Download bitmap
1~2040 Receipt: <= 1~384
Slip: 1~2040
Receipt: <= 98304
Slip: <=25856
Raster bitmap 1~65535 1~1023
One-line bitmap No setting range
Even if meet with the limitation described above, a bitmap that extend the paper
width cannot be printed.
z TM-U590
Bitmap command type Allowance range
X (dot) y (dot) xy Download bitmap
1~2040 1~2040 <= 25856
One-line bitmap No setting range
3.10 Color Bitmap Printing
The TM-H5000II/TM-U590 does not support color bitmap printing.
3.11 Maintenance Counter
The TM-H5000II/TM-U590 does not support the Maintenance Counter.
