Version 3.00 Feb. 2019
APPLICATION DEVELOPMENT GUIDE
POSPrinter (TM-H5000II/TM-U590)
5
4) Ethernet Port
DIP-SW1 DIP-SW2
No. Setting No. Setting
1 OFF Recommended 1 OFF Recommended
2 OFF Recommended 2 OFF Fixed at OFF
3 OFF Fixed at OFF 3 OFF Settable
4 OFF Fixed at OFF 4 OFF Settable
5 OFF Fixed at OFF 5 OFF Fixed at OFF
6 OFF Fixed at OFF 6 OFF Fixed at OFF
7 OFF Fixed at OFF 7 OFF Fixed at OFF
8 OFF Fixed at OFF 8 ON Fixed at ON
It is possible to change the settings of DIP-SW1-1 (Auto line feed) and
DIP-SW1-2 (Specification of the received buffer capacity), but it is recommended
to leave them OFF.
Set DIP-SW2-3 and DIP-SW2-4 (Specification of the print density) to match the
environment of use.
Make other settings in accordance with the settings described above.
• For the TM-U590
DIP-SW2-3 and DIP-SW2-4 are not used. Fix them OFF.
To Next Page
