Chapter 2
Setup
Securing the Printer t
o the Installation Sur
face
Fo
r vertical installa
tion, use of
the fixing
tape is r
ecommended t
o secure the prin
ter to the in
stallation s
urface.
1
Lay the printer on its side
.
2
Remove the r
elease paper from one side of the fixing tape.
3
Attach the fixing tape
to the tw
o positions.
4
Remov
e the other release pa
per from the fixing tape
.
5
Place the printer on the instal
la
tion sur
face, and then hold
the printer do
wn to secure
it.
