46
Chapter 2
Setup
5
Connect the DC cable of the AC adap
ter to the pow
er supply connec
tor
.
6
Attach the rear c
over
. Pull out the DC ca
ble through the cutout
of the rear c
over
.
How to disconnect the DC cable
Make sure that the AC cable is not connected, and then hold the arrow-printed portion of the
connector to pull it straight out.
45
47
