Epson TM-T20II

28
Electrical Characteristics
Operating voltage DC 24V ± 7%
Current consumption
(24V, 25°C, standard
print density)
Standby Mean: Approximately 0.1 A
Operating Mean: Approximately 1.8 A
Note: When print ratio is approximately 18%
 Continuous printing for 50 lines (repeating 20H-7FH)
 Font A, 48 columns, ASCII character
 5 line feeding
 Autocutting
If printing is continuously performed with a high ratio, the overcurrent protection may be
activated and result in uneven print density or a low voltage error. Therefore, the printing
length must not exceed the following values when printing with high print ratio.
Print ratio: Number of dots being energized per one dot line/Total number of dots per one
dot line (576 dots)
6789
67890
ABCDE
BCDE
48 columns
Print ratio 80% 100%
Print example
Print length 30 mm {1.18"} 20 mm {0.79"}
58 mm {2.28"}
72 mm {2.83"}
